ELVIAL SL46 SI² CLASSIC
SL46 SI² CLASSIC is one of ELVIAL’s best selling aluminium profile solutions. It comes in both lift and slide and sliding editions and responds to various design requirements. Being versatile and aesthetically balanced, it has been integrated into numerous high profile and private residence projects. The system’s sash width is only 46mm making it a beautiful and highly functional option for your own project.
4
6
THE DESIGN
The S46 SI² CLASSIC classic bears the seal of the ELVIAL design philosophy. It’s straight lines and austere style allow it to fit design concepts that put an emphasis on the abundance of natural light. Spaces look and feel ample and comfortable with this fascinating design detail.
ATTENTION TO DETAILS
EXTRA FEATURES
THE TECHNOLOGY
This aluminium system is one of the most popular in its category. It is more than certain that you too will appreciate its efficiency as have many happy customers before you.
The Thermal Insulation
The SL46 SI² CLASSIC protects your space from trials of the weather. Hot, temperate or cooler climates meet their match.
-
22MM INSULATING BARS
Wide insulating bars of 22mm with glass fiber re-enforcement 25%, are applied to all system profiles, offering high thermal insulation levels and extra rigidity. -
CUSTOMIZED INSULATING BARS
The customized insulation bars are set both in the central zone and the middle mullion so the aluminium system is energy efficient and performs within ELVIAL standards.
The Total Sealing System
ELVIAL sliding systems are designed to offer the efficiency you need and the style you desire. The SL46 SI² CLASSIC is an exemplary case.
-
EFFICIENT PROTECTION
The profile is fitted with customized gaskets that keep your space neat and water tight.
Lift & Slide edition -
EFFICIENT PROTECTION
The profile features a specially developed combination of customized brushes with sealing membrane that ensure the efficient protection from wind and water.
Sliding edition
Durability For A Life Time
This collection has been proved to stand the test of time and has many devoted witnesses of its value.
-
HIGH QUALITY ROLLING
This solution can bear up to 250 kg per sash and maintain quality rolling. It is a perfect fit for spaces with wide openings and lets you enjoy your view. -
MAXIMUM STRENGTH
There are various reinforcements available in this system designed to match the wind pressure requirement you will prescribe.
Design
Sash Depth
46mm
Visible Height
Standard Edition
Standard Edition
121.8mm
Middle Mullion Width
Successive
Successive
sash 85.5mm
sash 52.7mm
89mm
56mm
Middle Mullion Width
Fixed T
Fixed T
56mm
Meeting Stile Construction Width
Meeting Stile
Meeting Stile
189mm
Properties
Max Sash Height
2.800mm
Max Sash Width
2.000mm
Max Sash Weight
400kg
Max Glass Thickness
30mm
Uf Value (≥)
4.1 W/m²K
Uw Value (=)
1.66 W/m²K
Air Permeability
Class 4
Water Tightness
4A
Wind Load Resistance
C2/B2
Sound Reduction
39dB
GET ACCESS
Are your Interested for more technical information about this product? Contact us and gain access to Technical Catalogue, DWG, BIM, Test Reports.
GET IN TOUCH
