ELVIAL SL46 SI²_MD

The SL46 SI²_MD appeals greatly to the more design sensitive. A sliding aluminium system equipped with special, stainless steel rollers, will prove its value over time and will also add an extra flair to the look and feel of your project.
ELVIAL SL46 SI²_MD
4
6
THE DESIGN
THE DESIGN
THE DESIGN

The SL46 SI²_MD is the sliding aluminium system that completes this collection’s offering. It’s graceful lines and sophisticated construction adhere to the trend of minimal and light flooded interiors.

ATTENTION TO DETAILS

POWERFUL DESIGN

We chose the narrow design to create the maximum access to the view that will surround you. The SL46 SI²_MD bears an internally reinforced narrow mullion. We eliminated the external reinforcement column so you can have it all.

FIRM AND MINIMAL

Beauty is not defenceless here. The reinforcement of this system sustains higher wind loads.

LINEAR DESIGN

The system is reinforced with special decorative caps that create a unified visual composite. We took the term ‘flat’ quite literally when designing this solution.

MINIMAL FRAME

The inner side of the system can be covered to leave a visible part of only 59mm. This system will let you be as restrained or bold as you wish with your choice of interior style.

BUILD IN TRUCKS

Τhe SL46 SI²_MD sports another tested design feature that you will greatly appreciate. The track of the profile is concealed by the floor, still efficient and watertight.

CONCEALED GASKETS

The gaskets of this aluminium system are fitted to go undetected around the perimeter of the glazing zone. The aluminium system is durable and effective plus very elegant.
POWERFUL DESIGN
FIRM AND MINIMAL
LINEAR DESIGN
MINIMAL FRAME
BUILD IN TRUCKS
CONCEALED GASKETS

EXTRA FEATURES

INNER HANDLE

Handles are so sophisticated that render a unique style to any architectural design. Function and appearance are in perfect harmony.

OUTER FLUSH PULL

The profile’s flush pulls on the outside are barely there. The frame looks even and sleek from every angle. Function and form are in perfect harmony.
INNER HANDLE
OUTER FLUSH PULL
THE TECHNOLOGY
THE TECHNOLOGY
THE TECHNOLOGY

The SL46 SI²_MD is more than just a pretty frame. The system is fitted with technologies of insulation and sealing that make sure your space is protected and energy efficient. Your choice of ELVIAL is justified and this is one of our priorities.

The Thermal Insulation

The Minimal Design edition of the SL46 SI² is manufactured to keep your space cozy and warm or cool and fresh when you so want or need it. It is an ELVIAL product so it could do no less.

  • 22MM INSULATING BARS

    Wide insulating bars of 22mm with glass fiber re-enforcement 25%, are applied to all system profiles, offering high thermal insulation levels and extra rigidity.

  • CUSTOMIZED INSULATING BARS

    Τhe middle mullion is fitted with customized insulating bars. The system's energy performance is optimized. The constant requirement of projects in temperate and hot climates is met.

The Total Sealing System

ELVIAL sliding systems are manufactured to offer the efficiency you need and the style you desire. The SL46 SI²_MD is an exemplary case.

  • EFFICIENT PROTECTION

    The profile features a specially developed combination of customized brushes with sealing membrane that ensure the efficient protection from wind and water.

Durability For A Life Time

This collection has been proved to stand the test of time and has many devoted witnesses of its value.

  • HIGH QUALITY ROLLING

    This solution can bear up to 250 kg per sash and maintain quality rolling. It is a perfect fit for spaces with wide openings and lets you enjoy your view.Τhe Minimal Design edition is further equipped with two rows of stainless steel rollers that will stay rust free and ensure your system works smoothly for many many years to come.

  • MAXIMUM STRENGTH

    There are various reinforcements available in this system designed to match the wind pressure requirement you will prescribe.
Design
Sash Depth
46mm
Visible Height
Standard Edition
80mm
Visible Height
Infloor Edition
59mm
Middle Mullion Width
Successive
56mm
Properties
Max Sash Height
2.300mm
Max Sash Width
1.200mm
Max Sash Weight
100kg
Max Glass Thickness
30mm
Uf Value (≥)
3.7 W/m²K
Uw Value (=)
1.67 W/m²K
GET ACCESS
Are your Interested for more technical information about this product? Contact us and gain access to Technical Catalogue, DWG, BIM, Test Reports.
GET IN TOUCH
